- Wripple Wall Paper Cup
Inquiry
Standard sizes:
100% food grade PE lining paper + double adhesive paper + corrugated paper
Remarks:The following dimensions are measured manually, and a slight error in size is normal.!
Ripple wall cup | Specification | Capacity(ml) | Upper diameter (mm) | Bottom width (mm) | Height(mm) | Quantity/bag (pcs) | Quantity/box (pcs) | Carton size (cm) |
---|---|---|---|---|---|---|---|---|
Vertical ripple wall cup | 4 | 120 | 62 | 45 | 62 | 25 | 500 | 32*25.5*34.5 |
7 | 200 | 72 | 49 | 78 | 25 | 1200 | 59*38*36 | |
9 | 260 | 78 | 55 | 91 | 30 | 600 | 40*32*57 | |
11 | 330 | 80 | 53 | 111 | 20 | 400 | 45*36*48 | |
12 | 400 | 90 | 60 | 112 | 20 | 400 | 45*37*43 | |
16 | 500 | 90 | 60 | 135 | 20 | 400 | 46*37*52 | |
22 | 650 | 90 | 60 | 165 | 20 | 400 | 46*37*63 | |
Screw thread ripple wall cup | 9 | 260 | 78 | 55 | 91 | 30 | 600 | 40*32*57 |
12 | 400 | 90 | 60 | 112 | 20 | 400 | 45*37*43 | |
16 | 500 | 90 | 60 | 135 | 20 | 400 | 46*37*52 | |
22 | 650 | 90 | 60 | 165 | 20 | 400 | 46*37*63 | |
S-ripple wall cup | 9 | 260 | 78 | 55 | 91 | 30 | 600 | 40*32*57 |
12 | 400 | 90 | 60 | 112 | 20 | 400 | 45*37*43 | |
16 | 500 | 90 | 60 | 135 | 20 | 400 | 46*37*52 |
